S Simplex Type – PT-PT-RH 10% – 0.3 SWG – 16mm X 600mm Ceramic Tube

YOG S-Type Simplex Thermocouple – Pt-PtRh10%, 0.3 SWG, with Ceramic Tube (16mm x 600mm)

The YOG S-Type Simplex Thermocouple is designed for precise and stable temperature measurement in extremely high-temperature environments such as furnaces, kilns, and metal processing industries. Constructed with Pt-PtRh10% (Platinum-Rhodium) elements in 0.3 SWG, this sensor ensures high accuracy and long-term stability even under thermal cycling.

It features a 16mm x 600mm KER 710 ceramic protection tube, known for its excellent thermal shock resistance and insulation properties at high temperatures. A 135mm long SS304 holding sleeve enhances mechanical strength and ensures safe mounting.

The assembly is terminated with a rugged aluminum head with flange, making it easy to install and secure in high-heat process environments.

Ideal for applications requiring highly accurate and reliable measurements in temperatures often exceeding conventional sensor limits.

🔧 Technical Specifications:

• Make: YOG

• Type: S Type Simplex (Pt-PtRh10%) – 0.3 SWG

• Protection Tube: 16mm x 600mm (KER 710 Ceramic)

• Holding Sleeve: 135mm Long (SS304)

• Termination: Aluminum Head with Flange

• Application: High-temperature industrial processes, furnaces, kilns
